Product hire
Diamond 19 LED Wash
The Diamond 19 LED Wash is an RGBW wash lighting fixture designed for use in stage, studio, and architectural settings. It contains 19 individual RGBW LEDs and supports motorised zoom with a beam angle range of 10° to 60°.
The fixture supports DMX512 and RDM control protocols via 3-pin and 5-pin XLR connectors. Multiple DMX channel modes are available to accommodate different control requirements. The output is flicker-free and the unit operates with low noise due to active fan management.
Power input is auto-ranging from 100–240 V AC at 50/60 Hz. Typical power consumption is approximately 280 W at 230 V. The housing is rated IP20 for indoor use and is constructed from metal with a black finish.
Physical dimensions are approximately 338 × 449 × 235 mm. The fixture weighs around 11.1 kg.
Dimensions: 338 x 449 x 235mm
Weight: 11.1Kg
Flying Weight: 12.32 Kg
Power and Current: 280W, 1.22A @ 230V, 50Hz (Inrush current ＜50A @ 230V)
Waterproof: IP20
